Page 42
6.
Navigate to and select the new firmware file. Click Open. The Choose Firmware File
window closes.
NOTE: When downloaded from the Extron Web site, the firmware is placed in a
subfolder of C:\Program Files\Extron\Firmware.
ATTENTION: The firmware file must have a .S19 extension. Other file types can
cause the unit to stop functioning.
7.
In the Firmware Loader window, click Begin (see figure 24).
The Total Progress and Progress status bars show the progress of the upload. The
firmware upload to the unit may take several minutes. Once the status bars have
progressed from 0% to 100%, and Status is listed as Completed, the firmware loader
utility resets the unit.
7
Figure 24.
Firmware Loader Screen
8.
Click Exit to close the Firmware Loader.
PowerCage FOX HDMI • Remote Control
36
