HDMI output connector — Connect a video display to this HDMI connector .
HDMI
See “
“ on the next page for pin assignments and to use the
LockIt HDMI Cable Lacing Bracket to secure the connector to the receiver.
i
Audio output connector (receivers) — This 5-pole, 3.5 mm captive
L
R
AUDIO
screw connector outputs the transmitted, unamplified, line level audio.
Connect audio devices, such as an audio amplifier or powered speakers. See
“
“ on page 12 to wire a captive screw connector
for the appropriate output type and impedance level.
j
Audio switch — This switch mutes (Off) and unmutes (On) the embedded audio
ON
AUDIO
OFF
output on the HDMI output connector. The audio on the captive screw audio
output always remains active regardless of the setting of this switch.
k
Signal LEDs — These indicators light when the transmitter or receiver senses
HDMI
HDCP
AUDIO
that the associated signal is input (transmitter) or received on the fiber optic
cable (receiver).
•
HDMI — The unit is sensing an HDMI input signal.
•
HDCP — The input signal is HDCP encrypted.
•
Audio — The unit is sensing an audio input signal above –35 dBV. The LED turns off
if the audio signal level drops below the threshold for 10 seconds.
l
Power LED
— This LED lights to indicate that power is applied to the unit through the
PowerCage backplane.
