Command and Response Table for Receiver SIS Commands (continued)
Command ASCII Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Auto memory
Disable auto memory 55*0# Img0 ]
Enable auto memory 55*1# Img1 ]
Show auto memory status 55# X(]
Audio mute
Mute the audio 1Z Amt1 ] Silence the audio output of the receiver.
Unmute the audio 0Z Amt0 ] The receiver outputs audio.
Show audio mute status Z X(] Audio mute status is X( .
Test patterns
NOTE: You must have a video input connected to the transmitter and the transmitter-Tx-to-receiver-Rx fiber cable connected for the
receiver to output a selected test pattern. The test pattern turns off if the input signal rate changes or is disconnected or if power
is removed.
Output color bars 1J Tst1 ] Set the receiver to output the color bars test pattern.
Output grayscale 2J Tst2 ] Set the receiver to output the grayscale test pattern.
Output alternating pixels 3J Tst3 ] Set the receiver to output the alternating pixels test
pattern.
Turn test pattern off 0J Tst0 ] Set the receiver to output the input video (no test
pattern is selected).
Show test pattern status J X1&]
Disable and enable return link and daisy chain
NOTE: The disable return link function is primarily used and recommended when the transmitting device is a FOX 500 DA6 and the
receiver is connected to any of outputs 2 through 6 on the DA.
Disable return link 66*0*0# Rle*0*0 ] Disable link 2.
Enable return link to
transmitter 66*0*1# Rle*0*1 ] Enable link 2 (default setting).
Enable daisy chain 66*0*2# Rle*0*2 ] Enable receiver daisy chain mode.
Show return link and daisy
chain status 66*0# 0* X1*]
Video bit depth
Set video bit depth to auto E V0BITD } BitdV0 ]
Force video to 8-bit depth E V1BITD } BitdV1 ]
View video bit depth E VBITD } X1(]
HDCP notification
Enable notification E N1HDCP} HdcpN1]
Disable notification E N0HDCP} HdcpN0]
View notification status E NHDCP} X(]
NOTES: • The Set Video Delay command delays the digital video to help monitors sync correctly during an input rate change.
• Only video is delayed. Embedded audio is not delayed.
Set video delay 3* X1% # Dly X2)]
Show video delay 3# X2)]
NOTE: X( = Mute and auto memory status 0 = off 1 = on
X1$ = Horizontal and vertical position 000 through 255
X1& = Test pattern 0 = none 2 = grayscale
1 = color bars 3 = alternating pixels
X1* = Rx link and daisy chain enable 0 = disable 1 = return link enable 2 = daisy chain enable
X1( = Video bit depth 0 = auto 1 = 8-bit
PowerCage FOX HDMI • Remote Control 24
