Symbol definitions for receiver SIS commands
]
= Carriage return/line feed
}
= Carriage return (no line feed)
| = Pipe (can be used interchangeably with the
}
character)
• = space
E
= Escape key
W = Can be used interchangeably with the
E
character
X(
= Mute or auto memory status and enable or disable status 0 = off or disable 1 = on or enable
X1)
= Link and input status 0 = link or input not detected 1 = link or input detected
X1!
= Internal temperature nnnF•nnC
X1@
= Transmission mode SM = singlemode MM = multimode
X1#
= Firmware version v.vv
X1$
= Sync frequency xxx.xx (frequency in kHz [H] or Hz [V])
X1%
= Horizontal and vertical position 000 through 255
X1^
= Memory preset number 01 through 30
X1&
= Test pattern 0 = none 2 = grayscale
1 = color bars 3 = alternating pixels
X1*
= Rx link and daisy chain enable 0 = disable 2 = daisy chain enable
1 = return link enable
X1(
= Video bit depth 0 = auto 1 = 8-bit
X2)
= Video delay (0 plus six steps at 0.25 seconds per step) 0 = 0 second
1 = 0.25 second
4 = 1.0 second
2 = 0.5 second (default) 5 = 1.25 second
3 = 0.75 second 6 = 1.5 second
X2!
= Switch position 0 = off (right) 1 = on (left)
Command and Response Table for Receiver SIS Commands
Command ASCII Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Video mute
Mute output 1B Blk1 ] Blank the video output.
Unmute output 0B Blk0 ] Output video.
Show video mute status B X(] Video mute status is X( .
Horizontal shift
Set a horizontal position X1% H Hph X1%] Set horizontal centering to X1% .
Increment position +H Hph X1%] Shift the image one pixel to the right.
Decrement position –H Hph X1%] Shift the image one pixel to the left.
Show position H X1%]
Vertical shift
Set a vertical position X1% / Vph X1%] Set vertical centering to X1% .
Increment position +/ Vph X1%] Shift the image down one line.
Decrement position –/ Vph X1%] Shift the image up line.
Show position / X1%]
List sync frequency
View input frequency 1LS X1$ horizontal , X1$ vertical ] Shows horizontal frequency in kHz and vertical
frequency in Hz. 000.0,000.0 if no signal is
detected.
Memory presets
Save preset X1^ , Spr X1^] Command code is a comma.
Recall preset X1^ . Rpr X1^] Command code is a period.
NOTE: X( = Mute and auto memory status 0 = off 1 = on
X1$ = Horizontal and vertical position 000 through 255
X1% = Sync frequency xxx.xx (frequency in kHz [H] or Hz [V])
X1^ = Memory preset number 01 to 30
PowerCage FOX HDMI • Remote Control 23
