Brightness/Contrast: Brightness adjusts the light intensity of the image on the
screen. Contrast adjusts the difference between the brightest and darkest settings
of the input signal.
The brightness adjustment is also available by using the front panel or IR remote
control to select Menu > Picture > Brightness in the main menu system (see
“
Brightness status indicator bar
The contrast adjustment is also available by using the front panel or IR remote
control to select Menu > Picture > Contrast in the main menu system (see
“
” on page 26).
•
Color/Tint: Color increases and decreases the color intensity of the picture. Tint is a
relative measure of the amount of white in a given color and adjusts the color of the
picture toward red or green.
The color adjustment is also available by using the front panel or IR remote control
to select Menu > Picture > Color in the main menu system (see “
” on page 26).
The tint adjustment is also available by selecting Menu > Picture > Tint in the main
menu system (see “
” on page 27).
•
Zoom (IR remote control only): Zoom enlarges a portion of the scaled image.
This adjustment is also available by using the front panel or IR remote control to
select Menu > Input > Zoom in the main menu system (see “
•
Pan (IR remote control only): Pan shifts the center of the image on an image that
has been zoomed in on.
NOTE: Pan is available only for an image that has been zoomed in.
This adjustment is also available by using the front panel or IR remote control to
select Menu > Input > Pan in the main menu system (see “
”).
•
Sharpness filter (IR remote control only): The adjustment range is from 0 to 128.
This adjustment is also available by using the front panel or IR remote control to
select Menu > Picture > Sharpness in the main menu system (see “
•
Fine pixel phase (IR remote control only): The adjustment range is from 0 to 31.
This adjustment is also available by using the front panel or IR remote control to
select Menu > Input > Advance > Phase in the main menu system (see “
NOTE: Pixel phase is available only for YUVp, HDTV, and RGB inputs.
3.
For the aspect ratio selection box, use the and buttons to toggle back and forth
between the two selections: 4:3 and 16:9.
This adjustment is also available by using the front panel or IR remote control to select
Menu > Input > Aspect in the main menu system (see “
page 25).
4.
Repeat steps 1 and 2 for each image adjustment to be made for that input.
5.
If you want to set picture adjustment on another input, press the appropriate input
button.
IN1508 • Operation
37
