DXP DVI Pro and DXP HDMI Series • SIS Configuration and Control
61
Command
ASCII Command
(Host to Switcher)
Response
(Switcher to Host)
Additional Description
I/O Grouping
NOTE:
The group that is assigned in each of the following I/O grouping commands (
X%
) must be 1, 2, 3, 4, or 0 (not
grouped).
Write input grouping
EX%
X%
...
X%
n
I
}
Gri
X%
X%
X%
...
X%
n
]
Each
X%
entry is the group
number assigned to an input
position, starting from input 1.
n = the maximum number of
inputs for this model.
Example:
DXP DVI Pro 88
DXP HDMI 88
E
40...2I
}
1
Input:
Gri
Response #s = group:
Input 1 in
group 4
2 3 4 5 6 7 8
4 0 1 3 3 0 0 2
Input 2 not
grouped
Input 8 in
group 2
Input 1 – group 4
input 2 – group 0 (ungrouped)
input 8 – group 2
Write output grouping
EX%
X%
...
X%
n
O
}
Gro
X%
X%
X%
...
X%
n
]
Each
X%
entry is the group
number assigned to an output
position, starting from output 1.
n = the maximum number of
outputs for this model.
Read input grouping
E
I
}
X%
X%
X%
...
X%
n
]
Each
X%
entry is the group
number assigned to an input
position, starting from Input 1.
n = the maximum number of
inputs for this model.
Example:
DXP DVI Pro 88
DXP HDMI 88
E
I
}
1
Input:
Response = group:
Input 1 in
Group 1
2 3 4 5 6 7 8
1 1 0 3
0
Input 3 Not
Grouped
Input 8 in
Group 3
3
0 0
Read output grouping
E
O
}
X%
X%
X%
...
X%
n
]
Each
X%
entry is the group
number assigned to an output
position, starting at Output 1.
n = the maximum number of
outputs for this model.
Names
Write global preset name
EX&,X1#
NG
}
Nmg
X&,X1#]
Assign global preset
X&
the
name
X1#
.
Example:
E
1,Security 1NG
}
Nmg01
,
Security1
]
Name global preset 1
Security 1.
Read global preset name
EX&
NG
}
X1#]
View the name assigned to
global preset number
X&
.
Example:
E
2NG
}
Security 2
]
Write room name
EX^,X1#
NR
}
Nmr
X^,X1#]
Assign room preset
X^
the
name
X1#
.
Example:
E
1
,
Classrm 1NR
}
Nmr01
,
Classrm1
]
Name room 1 Classrm 1.
Read room name
EX^
NR
}
X1#]
NOTE:
X@
= Input number (for ties)
0 – maximum number of inputs for your model
X%
= Group number
1 – 4. 0 = ungrouped
X^
= Room number (for room presets)
Each room can have up to 10 presets (
X*
) assigned.
X&
= Global preset number
00 – 32. 00 = current preset
X1#
= Name
Name of preset, room, input, or output
•
12 characters maximum for input, output, and global preset names
•
11 characters maximum for room names
•
Upper- and lowercase alphanumeric characters are valid.
