SIS Command and Response T
able for IP Contr
ol Port
Command
ASCII (T
elnet)
(host to pr
ocessor)
URL Encoded (W
eb)
(host to pr
ocessor)
Response (pr
ocessor to host)
Additional Description
Ether
net data port
Set curr
ent connection
port timeout
E
0*
X12&
TC
}
W 0%2A
X12&
TC
Pti0
*
X12&]
V
iew curr
ent connection
port timeout
E
0TC
}
W 0TC
X12&]
Set global IP port timeout
E
1*
X12&
TC
}
W 1%2A
X12&
TC
Pti1*
X12&]
V
iew global IP port
timeout
E
1TC
}
W 1TC
X12&]
Firmwar
e version r
equests
NOTE:
An asterisk (*) after the version number indicates the version curr
ently running. Car
et (^) indicates bad checksum/invalid load. Question marks (?) indicate version not
loaded.
Query firmwar
e version
Q or 1Q
Q or 1Q
X13!]
Show the scaler firmwar
e version
number (
X13!
) to two decimal places. Gives
the number of the curr
ently running version
of the user
-updatable firmwar
e.
Query verbose version information
0Q
0Q
All r
esponses
fr
om 2Q-3Q-4Q
]
Show bootstrap, factory-installed, and updated firmwar
e versions. (See 2Q, 3Q,
and 4Q, below
.)
Example:
1Q
1Q
1.01
Query bootstrap version
2Q
2Q
X13!]
The bootstrap firmwar
e is not user
-
replaceable but you may need this information for tr
oubleshooting.
Example:
2Q
2Q
0.06
Query factory firmwar
e
version
3Q
3Q
X13!
(plus web ver
.-
desc-date/time)
]
Factory-installed firmwar
e is not user
replaceable. This firmwar
e is the version
the pr
ocessor r
everts to after a mode 1 r
eset
(see “Operation” section).
Example
:
3Q
3Q
1.00(1.37-DVS 605 Series -Fri, 12 Aug 2012 03:28:10 GMT)
In this example, the factory firmwar
e version
is 1.00, (the ker
nel version 1.37), for the
DVS 605, dated 12 August, 2012.
NOTE:
X12&
= The number of seconds befor
e timeout on the IP connection: (min. = 1; max. = 65000; default = 30 = 300 seconds)
X13!
= V
ersion number (listed to 2 decimal places)
DVS 605 • SIS Communication and Control 56
