Command
ASCII Command
(host to scaler)
Response
(scaler to host)
Additional Description
Input name
Write input name
EX!
,X1$NI}
NmiX!,X1$]
Set the name X1$ for input X!.
Read input name
EX!
NI}
X1$]
View input X!
name X1$.
NOTE:
To clear an input name, a single space character should be entered for
X1$
. This resets the input name to the
default value.
Auto-Image
Enable
X!
*1A
ImgX!*1]
Activate Auto-Image for input
X!
.
Disable
X!
*0A
ImgX!*0]
Turn Auto-Image off for input
X!
.
View status
X!
A
X(]
View Auto-Image setting: (0 = on,
1 = off).
Execute
0*A
Img0]
Execute an Auto-Image to the selected
input (follows current aspect setting).
Execute and Fill
1*A
Img1]
Execute an Auto-Image and fill entire
output.
Execute and Follow
2*A
Img2]
Execute an Auto-Image and follow the
aspect ratio of the input.
Auto-Image threshold value
(minimum luminosity value which the scaler defines as active video for Auto-Image
)
Set value
EX3@
ALVL}
AlvlX3@]
Set global Auto-Image luminosity value
X3@
.
View
E
ALVL}
X3@]
View global Auto-Image luminosity value
X3@
.
Horizontal start
Specify a value
E
X!
*X$HSRT}
HsrtX!*X$]
Set horizontal location of first active pixel
for input
X!
.
Increment value
E
X!
+HSRT}
HsrtX!*X$]
Increment horizontal start position.
Decrement value
E
X!
-HSRT}
HsrtX!*X$]
Decrement horizontal start position.
View
E
X!
HSRT}
X$]
Show horizontal location of first active
pixel for input
X!
.
Vertical start
Specify a value
E
X!
*X$VSRT}
VsrtX!*X$]
Set vertical location of first active pixel for
input
X!
.
Increment value
E
X!
+VSRT}
VsrtX!*X$]
Increase vertical start.
Decrement value
E
X!
-VSRT}
VsrtX!*X$]
Decrease vertical start.
View
E
X!
VSRT}
X$]
Show vertical location of first active pixel
for input
X!
.
NOTE:
X! = Input selection: 1 to 5
X$ = Horizontal/vertical start: 0 to 255 (default midpoint = 128)
X( = Enable/disable: 0 = off/disable, 1 = on/enable
X1$ = Text label/preset name, up to 16 characters
X3@ = Auto-Image threshold value: 0 (black) though 100 (white), default = 25
DVS 605 • SIS Communication and Control
43
