Page 57
Command
ASCII Command
(host to scaler)
Response
(scaler to host)
Additional Description
Advanced Configuration
Test pattern
Set test pattern
E
X2)
TEST}
Test
X2)]
Set the test pattern to
X2)
.
View test pattern
E
TEST}
X2)]
View the current test pattern.
Freeze
Freeze all windows
1F
Frz1]
Freeze Main and PIP input windows.
Freeze only MAIN
window
2F
Frz2]
Freezes Main input window.
Freeze only PIP
window
3F
Frz3]
Freeze PIP input windows.
Disable
0F
Frz0]
Unfreeze all windows.
View
F
X(]
Show the freeze status (1= all frozen,
2 = Main frozen, 3 = PIP frozen, 0= all
unfrozen).
Auto memories (per input)
Enable
E
X!
*1AMEM}
Amem
X!
*1
]
Set auto memory on. Previous settings for
incoming signal are auto recalled.
Disable
E
X!
*0AMEM}
Amem
X!
*0
]
Set auto memory off. Manual recall of
input presets needed to configure input.
View setting
E
X!
AMEM}
X(]
View current auto memory for input
X!
.
Input aspect ratio (per input)
Enable Fill mode
E
X!
*1ASPR}
Aspr
X!
*1
]
Sets input
X!
to always fill the entire raster
(default).
Enable Follow
mode
E
X!
*2ASPR}
Aspr
X!
*2
]
Sets input
X!
to preserve its native aspect.
View aspect setting
E
X!
ASPR}
X2(]
View aspect ratio setting for input
X!.
Auto switch mode
Disable
E
0AUSW}
Ausw0]
Manual switching only (default).
Priority to highest
active
E
1AUSW}
Ausw1]
Gives priority to the highest numbered
active input.
Priority to lowest
active
E
2AUSW}
Ausw2]
Gives priority to the lowest numbered
active input.
View setting
E
AUSW}
X3&]
View the current auto switch mode.
NOTE:
X! = Input selection: 1 to 5
X( = Enable/disable: 0 = off/disable, 1 = on/enable
X2) = Test patterns:
0 = off (default)
4 = crosshatch
8 = ramp
12 = 1.85 aspect ratio
1 = crop
5 = 4x4 crosshatch 9 = white field
13 = 2.35 aspect ratio
2 = alternating pixels
6 = color bars
10 = 1.33 aspect ratio 14 = blue mode
3 = alternating lines
7 = grayscale
11 = 1.78 aspect ratio
X2( = Aspect ratio:
1 = fill; each input rate will automatically fill the entire output raster (default)
2 = follow; each input rate will be displayed with its native aspect ratio
X3& = Auto switch mode: 0 = disable (default), 1 = priority to highest numbered input, 2 = priority to lowest numbered input
DVS 605 • SIS Communication and Control
51
