Command ASCII Command
(host to scaler)
Response
(scaler to host)
Additional Description
Presets
User presets
Recall preset 1*X2#. 1RprX2#] Recall user preset X2# for selected input.
Save preset 1*X2#, 1SprX2#] Save user preset X2# for selected input.
Delete/clear preset E X1*X2#PRST} PrstX1*X2#] Clears user preset X2# , and sets user preset
X2# name to [unassigned].
User preset name
Write name E 1*X2#,X1$PNAM} Pnam1*X2#,X1$] Set the user preset X2# name to X1$ .
Read name E 1*X2#PNAM} X1$] Read the name for user preset X2# .
NOTE:
To restore a default user preset name, enter a single space character for X1$
; unassigned presets = “ [unassigned]”. Valid only
for previously saved presets.
Input presets
Recall preset 2*X2$. 2RprX2$] Recall input preset X2$ for selected input.
Save preset 2*X2$, 2SprX2$] Save input preset X2$ for selected input.
Delete/clear preset E X2*X2$PRST} PrstX2*X2$] Clears input preset X2$ , and sets input
preset X2$ name to [unassigned].
Input preset name
Write name E 2*X2$,X1$PNAM} Pnam2*X2$,X1$] Set the input preset X2$ to X1$ .
Read name E 2*X2$PNAM} X1$] Read the name for input preset X2$ .
NOTE: To restore a default input preset name, enter a single space character for X1$
; unassigned presets = “ [unassigned]”.
PIP presets
Recall preset
without input 3*X2#. 3RprX2#] Recall PIP preset X2# without inputs.
Recall preset
with input 4*X2#. 4RprX2#] Recall PIP preset X2# with inputs.
Save preset 4*X2#, 4SprX2#] Save PIP layout and inputs to preset X2# .
Delete/clear preset E X4*X2#PRST} PrstX4*X2#] Resets the PIP preset X2# , and PIP preset
X2# name back to default factory settings.
PIP preset name
Write name E 3*X2#,X1$PNAM} Pnam3*X2#,X1$] Set the PIP preset X2# to X1$ .
Read name E 3*X2#PNAM} X1$] Read the name for PIP preset X2# .
NOTE: To restore a default PIP preset name, enter a single space character for X1$
; default = “PIP preset XX” where “XX” is the current
preset number (for example 05) .
NOTE:
X1$ = Text label/preset name: up to 16 characters X2# = User presets or PIP presets: 1 to 16 X2$ = Input presets: 1 to 128
User Presets Input Presets PIP Presets
Color H/V Window
Position
Input Type Color H Start H/V Window
Position
Main H/V
Window Position
PIP H/V
Window Position
Tint H/V Window
Size
Preset Name Tint V Start H/V Window
Size
Main H/V
Window Size
PIP H/V
Window Size
Contrast H/V Image
Position
Audio Gain/
Attenuation Contrast H Active H/V Image
Position
Main H/V
Image Position
PIP H/V
Image Position
Brightness H/V Image
Size
Brightness V Active H/V Image
Size
Main H/V
Image Size
PIP H/V
Image Size
Detail Detail Phase Main Input #
Preset Name Film Mode Total Pixels PIP Input #
DVS 605 • SIS Communication and Control 50
