The matrix switchers are housed in rack-mountable, metal enclosures with 19” rack ears.
The amount of vertical rack space required for each switcher is as follows:
•
2U high enclosure
•
MAV Plus 84, 88, 124, and 128 HDA, HD, SVA, and SV switchers
•
MAV Plus 84, 88, 124, 128, 816, 164 (audio only), 168, 1212, and 1616 AV,
AV RCA, V, and A switchers
•
3U high enclosure
•
CrossPoint 84, 88, and 128 HV and HVA switchers
•
MAV Plus 168, 1212, and 1616 SVA and SV switchers
•
MAV Plus 328 and 248 A switchers
•
4U high enclosure
•
MAV Plus 168, 816, and 1616 HDA and HD switchers
•
5U high enclosure
•
MAV Plus 2412, 2424, 3216, and 3232 SV, AV, V, and A switchers
•
6U high enclosure
•
CrossPoint 168, and 1212, 1616 HV and HVA switchers
•
8U high enclosure
•
CrossPoint 450 Plus 2412 and 2424 HV and HVA switchers
•
MAV Plus 2412, 2424, 3216, and 3232 SVA switchers
•
10U high enclosure
•
CrossPoint 450 Plus 3216 and 3232 HV and HVA switchers
The appropriate rack mounting kit is included with each switcher.
