Components / scope of delivery DIQ/S 182 XT

1 - 1

ba76023e01

01/2012

Components / scope of delivery
DIQ/S 182 XT

Main components

Fig. 1-1

Main components

Scope of delivery

The DIQ/S 182 Universal Transmitter is delivered with an attached
DIQ/CR3 combination output module.

Note
Usage of the DIQ/CR3 is possible in conjunction with the System 182
only.

Operating manual

The operating manual consists of three parts:

Part 1: The part at hand with the description of the entire system

Part 2: Operating manual of the DIQ/S 182 (standard model)

Part 3: Operating manual of the DIQ/CR3 combination output model

Installation

Note
If any sensors with ultrasound cleaning function (e.g. VisoTurb 700 IQ
or ViSolid 700 IQ) are permanently in use in an environment with
temperatures over 50 °C (122 °F), an additional power supply module
is required.

DIQ/S 182

DIQ/CR3
