7 ups configuration requirements – GE Industrial Solutions ISM User Manual
Page 20
Modifications reserved
Page 20/34
OPM_ISM_OPT_10K_M50_0GB_V021.doc
Operating Manual ISM – Intelligent Synchronization Module
4.7 UPS CONFIGURATION REQUIREMENTS
WARNING !
The installation and connection must be performed by QUALIFIED SERVICE
PERSONNEL only.
Refer to the “Safety prescriptions - Installation” described on page 6.
NOTE !
The UPSs are already correctly configured, if they have been ordered and supplied
with the ISM.
Otherwise please make sure that UPSs connected with the ISM mount:
• P13 - IM0086 RPA Board with same software version as on the ISM.
• Following software versions on P3 - IM0007 Control Board:
-
For SitePro units: U2, U3: version 2.08 or higher; U36: version 7.0 or higher.
-
For SG Series units: U2, U3: version 3.06 or higher; U36: version 7.0 or higher.
