Modifications reserved Page 25/34
OPM_ISM_OPT_10K_M50_0GB_V021.doc Operating Manual ISM – Intelligent Synchronization Module
6.1 METERING MODE
The metering mode is entered any time when the metering button is pressed.
While in this mode the LCD will display a series of screens containing metering information.
In this mode the buttons perform the following functions:
METERING
Scrolls forward to the next screen.
ALARMS Abandons the metering mode and enters the alarms mode.
PARAMETERS Abandons the metering mode and enters the parameters mode.
+ Scrolls forward to the next screen.
– Scrolls backward to the previous screen.
ENTER Displays the main screen for this mode.
INTELL. SYNC MODULE
A sync to B
A: LOAD ON INVERTER
B: LOAD OFF PARAMETERS
METERING
ALARMS
ENTER
-
+
This screen displays the current status of the synchronization command and the UPS outputs (for both
Group A and B).
The information offered by this screen consists of:
• Synchronization: The status of the synchronization command (A sync to B, B sync to A or Sync
OFF).
• Group A: The source of the power supplied to the Load (LOAD ON INVERTER, LOAD ON
BYPASS, LOAD ON MAN. BYP. or LOAD OFF).
• Group B: The source of the power supplied to the Load (LOAD ON INVERTER, LOAD ON
BYPASS, LOAD ON MAN. BYP. or LOAD OFF).
OUTPUT STATUS
Synchronized
Load A = 50%
Load B = 20%
PARAMETERS
METERING
ALARMS
ENTER
-
+
This screen displays the load of UPSs output (for both Group A and B).
The information offered by this screen consists of:
• Synchronization status between UPSs of Group A and B;
• The load amount as a percentage of the nominal load of Group A (referred to the most loaded
phase);
• The load amount as a percentage of the nominal load of Group B (referred to the most loaded
phase).
MISCELLANEOUS
ISMOperTime : 123451h
SW Version : XXX-YYY
S/N: 72-97756 PARAMETERS
METERING
ALARMS
ENTER
-
+
This screen displays miscellaneous information.
The information offered by this screen consists of:
• The total operating time of the ISM (in hours).
• The software version.
• The serial number.
