6.3 USER PARAMETERS
The parameters mode is entered any time when the PARAMETERS button is pressed.
The LCD will display a series of screens containing the user parameters, accessible without password
protection.
The buttons perform the following functions:
METERING Abandons parameters mode and enters metering mode.
ALARMS Abandons parameters mode and enters alarms mode.
PARAMETERS Scrolls forward to the next screen.
+ Scrolls forward to the next screen.
– Selects from the current screen the parameter to edit.
ENTER Starts the editing for the currently selected parameter.
NOTE !
During parameters mode there is no means to perform scroll back on the display.
Example of operation within parameters mode:
Purpose: To correct a wrong parameter:
PROCEDURE DATE TIME LANG.
-
Enter parameters mode (PARAMETERS). The first screen is displayed. √ √ √
-
Scroll to the next screen (+). The second screen is displayed. √
-
Move the selection (underscore cursor) to the next parameter in this page (-). √
-
Enter Edit mode for the currently selected parameter (ENTER). √ √ √
DATE AND TIME
D M Y
Date: 15.09.2003
Time: 12:15:45
PARAMETERS
ALARMS
ENTER
-
+
METERING
1- DATE AND TIME
•
D = Day M = Month Y = Year.
• Date The set value is thoroughly checked to be a correct format “dd.mm.yyyy”.
• Time The set value is thoroughly checked to be a correct format “hh.mm.ss”.
LCD DISPLAY
Language = ENGLISH
PARAMETERS
ALARMS
ENTER
-
+
METERING
2- LCD DISPLAY
•
Language This parameter allows the choice of language used to display the information.
Valid choice is English.
