2.1.6 General Commands (Acknowledged)
DRIVE Response Command Subcommand
NPA Object
no.
Attribute Message Type Error Code Comments
ACK 0 4 -
Poll Message
No Acknowledge
-
The slave is to respond with any data points,
analog or binary I/O that have been flagged
for COS
ACK 0 5 -
Poll message
With Acknowledge
-
The slave is to respond with any data points,
analog or binary I/O that have been flagged
for COS
ACK 0 9 - Status update Message -
Slave device must respond with device man-
ufacturing model number (Par. AN-21), days in
service (Par. AN-00) and device status
ACK F - - Identify Device Type -
Slave device responds with an identification
number of 10H to indicate non JCI device
ACK 0 0 - Synch Time -
The internal clock is syncronized by this com-
mand
ACK, no action 8 0 - Upload -
Optional, no support in the frequency
converter
ACK, no action 8 1 - Upload -
Optional, no support in the frequency
converter
ACK, no action 8 3 - Upload Record -
Optional, no support in the frequency
converter
ACK, no action 8 4 - Upload Complete -
Optional, no support in the frequency
converter
ACK, no action 9 0 - Download -
Optional, no support in the frequency
converter
ACK, no action 9 1 - Download -
Optional, no support in the frequency
converter
ACK, no action 9 3 - Download -
Record optional, no support in the frequency
converter
ACK, no action 9 4 - Download Complete -
Optional, no support in the frequency
converter
NAK 0 1 - Read Memory 01
Slave device memory read based on memory
addresses
NAK 0 8 - Warm Start 01 JCI use only
Table 2.1: No Region, Attribute Number and -type in this table.
