2.1.15 Internal Integers (ADI) Commands (Acknowledged)
DRIVE
Response
Command Subcom-
mand
Region NPA Object no. Attribute No. Attribute Message Type Comments
ACK 1 - 6 0-254 1 Integer Read Internal Pa-
rameter of object
type integer (16 bit)
Read Object Status associ-
ated with each individual
point
ACK 1 - 6 0-254 2 Integer Read Internal Pa-
rameter of object
type integer (16bit)
Read Current Value attribute
associated with each
individual point
ACK 2 - 6 0-254 - Integer Write Internal Pa-
rameter of object
type integer (16bit)
Write to Current Value attrib-
ute associated with each
individual point
ACK 7 2 6 0-254 - Integer Override Internal
Parameter of ob-
ject type Integer
(16 bit)
Write to internal parameter
current value (set-up para-
meters for Drive)
ACK 7 3 6 0-254 - - Override Release Set the current value, the val-
ue that it was before the 1.
Override Command was
issued
Table 2.9: No Error Code coloumn in this table.
2.1.16 Internal Floating Point Commands (Acknowledged)
DRIVE
Response
Command Subcom-
mand
Region NPA Object no. Attribute No. Attribute Message Type Comments
ACK 1 - 5 0-101 1 Byte Read Internal Pa-
rameter of object
type float
Read Object Status associ-
ated with each individual
point
ACK 1 - 5 0-101 2 Float Read Internal Pa-
rameter of object
type float
Read Current Value attrib-
ute associated with each
individual point
ACK 2 - 5 0-101 - Float Write Internal Pa-
rameter of object
type float
Write to Current Value
attribute associated with
each individual point
ACK 2 - 5 0-101 - Float Write Internal Pa-
rameter of object
type float
Write to Current Value
attribute associated with
each individual point
ACK 7 2 5 0-101 - Float Override Internal
Parameter of object
type float
Write to internal parameter
current value (set-up
parameters for Drive)
ACK 7 3 5 0-101 - - Override Release Set the current value, the
value that it was before the
1. Override Command was
issued
Table 2.10: No Error Code coloumn in this table.
