2.1.9 Analog Output Commands (Acknowledged)
DRIVE
Response
Command Sub
command
Region NPA Object no. Attribute No. Attribute Message Type Comments
ACK 1 - 3 0-2 1 Byte Read Analog Output Read Object Configuration attrib-
ute associated with each
individual point
ACK 1 - 3 0-2 2 Byte Read Analog Output Read Object Status attribute asso-
ciated with each individual point
ACK 0 9 - - - - Status update Mes-
sage
Slave device must respond with
device manufacturing model
number (Par. AN-21), days in ser-
vice (Par. AN-00) and device status
ACK 1 - 3 0-2 3 Float Read Analog Output Read Current Value attribute asso-
ciated with each individual point
ACK 2 - 3 0-2 1 Byte Write Analog Output Write to Object Configuration at-
tribute associated with each
individual point
ACK 7 2 3 0-2 - Float Override Analog Out-
put
Write to analog output current
value (frequency setpoint)
ACK 7 2 3 0-2 - Float Override Analog Out-
put
Write to analog output current
value (frequency setpoint)
ACK 7 3 3 0-2 - - Override Release Set the current value, the value
that it was before the 1. Override
Command was issued
ACK, no action 7 7 3 0-2 - - Write Analog Output Optional command for slave devi-
ces. Only used for N2 Attributes
commissioning purposes. Not to
be implemented at this time
ACK, no action 7 8 3 0-2 - - Read Analog Output
Attributes
Optional command for no action
slave devices. Only used for N2
commissioning purposes. Not to
be implemented at this time
Table 2.4: No Error Code coloumn in this table.
