Binary Inputs (BI), continued..
NPT NPA UNIT DESCRIPTION SELECTION PAR. NUMBER
BI 98 - Off 0=FALSE , 1=TRUE DR-94/95
BI 99 - Local Reference 0=Remote ref., 1=Local ref. DR-94/95
BI 100 - Running 0=FALSE, 1=TRUE DR-94/95
BI 101 - Running at reference 0=FALSE , 1=TRUE DR-94/95
BI 102 - Reverse direction 0=FALSE , 1=TRUE DR-94/95
BI 103 - Ramping 0=FALSE , 1=TRUE DR-94/95
BI 104 - Start forward reverse 0=FALSE , 1=TRUE DR-94/95
BI 105 -
Adaptive tuning run-
ning
0=FALSE , 1=TRUE DR-94/95
BI 106 -
Adaptive tuning finish-
ed
0=FALSE , 1=TRUE DR-94/95
BI 107 - Sleep mode 0=FALSE , 1=TRUE DR-94/95
BI 108 - Sleep boost 0=FALSE , 1=TRUE DR-94/95
BI 109 - Start delay 0=FALSE , 1=TRUE DR-94/95
BI 110 - OVC active (Auto ramp) 0=FALSE , 1=TRUE DR-94/95
BI 112 - Ramp 0=RAMP 1 , 1=RAMP 2 DR-00
BI 113 - Reverse 0=No function , 1=reverse DR-00
BI 114 - Setup MSB 0=FALSE , 1=TRUE DR-00
BI 115 - Setup LSB 0=FALSE , 1=TRUE DR-00
BI 116 - Relay02
0=Relay04 off , 1=Relay04
on
DR-00
BI 117 - Relay01
0=Relay01 off , 1=Relay01
on
DR-00
BI 118 -
Res., always 0 (data val-
id)
0=FALSE DR-00
BI 119 - Jog 0=No Function , 1=Jog DR-00
BI 120 - Reset 0=No Function , 1=Reset DR-00
BI 121 - Start 0=start , 1=stop DR-00
BI 122 - Freeze output
0=Freeze output , 1=Ramp-
ing
DR-00
BI 123 - Q-stop 0=Q-stop , 1=Ramping DR-00
BI 124 - Coast 0=Coasting , 1=no Coast DR-00
BI 125 - DC brake 0=DC Brake , 1=Ramp stop DR-00
BI 126 - Preset ref. MSB 0=FALSE , 1=TRUE DR-00
BI 127 - Preset ref. LSB 0=FALSE , 1=TRUE DR-00
BI 128 - Terminal 33 0=FALSE , 1=TRUE DR-60
BI 129 - Terminal 32 0=FALSE , 1=TRUE DR-60
BI 130 - Terminal 29 0=FALSE , 1=TRUE DR-60
BI 131 - Terminal 27 0=FALSE , 1=TRUE DR-60
BI 132 - Terminal 19 0=FALSE , 1=TRUE DR-60
BI 133 - Terminal 18 0=FALSE , 1=TRUE DR-60
BI 134 - GPIO Term X30/2 0=FALSE , 1=TRUE DR-60
BI 135 - GPIO Term X30/3 0=FALSE , 1=TRUE DR-60
