Example 3:
Over-ride analog output, speed (50%) change command:
Setting:
Device address
XX
Char1 command
7
Char1 subcommand
2
Char2 region
03
Char2 object number (NPA)
00
Char8 override value *
4E 00 00 00 override value = 50% speed (IEEE floating point, format)
Checksum
YY
Message code:
>XX7203004E000000
To calculate override value for speed: refer to Scaling of Network Reference
and Network Feedback. Issue an override release command through the
master to the device:
Example 4:
Bus stop, BO over-ride release command:
Setting:
Device address
XX
Char1 command
7
Char1 subcommand
2
Char2 region
04
Char2 object number (NPA)
04 (Start)
Char8 override value *
00 (Not active)
Checksum
Y
Message code:
>XX72040400YY
If the preceding commands were issued, the drive should have accelerated
to 50% after the speed reference was issued. After the override release, the
drive should have stopped.
2.2.2 Scaling of Bus Reference and Feedback
Reference/feedback
Scaling
Float
IEEX hex
20%
20 * 16384/100
3276.8
454C CCCD
50%
50 * 16384/100
8192
4600 0000
100%
100 * 16384/100
16384
4680 0000
200%
200 * 16384/100
32767
46FF FE00
-100%
-100 * 16384/100
-16384
C680 0000
-200%
-200 * 16384/100
-32768
C700 0000
Table 2.11: Reference/feedback values
The reference/feedback value is the percentage of the range of parameter F-52 and F-53. Values within the ranges 100% to 200% and -200% to -100% applies
only to the reference. The Float representation of the value 200% must be limited to maximum 32767 and minimum -32768.
