2.1.10 Analog Output Commands (Not Acknowledged)
DRIVE
Response
Command Region NPA Object no. Attribute No. Attribute Message Type Error Code Comments
0-2 1 3 0-2 4 Float Read Analog Output 11 1 Read Low Linear Ranging Parameter
attribute associated with each
individual point. (JCI use only)
NAK 1 3 0-2 5 Float Read Analog Output 11 1 Read High Linear Ranging Para-
meter attribute associated with
each individual point. (JCI use only)
NAK 2 3 0-2 2 Byte Write Analog Out-
put
11 1 Object Status not writeable
NAK 2 3 0-2 3 Float Write Analog Out-
put
11 1 Write to Current Value structure at-
tributes associated with each
individual point. (N2 does not sup-
port this, override function must be
used)
NAK 2 3 0-2 4 Float Write Analog Out-
put
11 1 Write Debouncing Value in msec at-
tribute associated with each
individual point.(JCI use only)
NAK 2 3 0-2 5 Float Write Analog Out-
put
11 1 Write Accumulator value attribute
associated with each individual
point. (JCI use only)
1) Error code 11 is used because attributes are considered as fields/records in the point map database.
Table 2.5: No Subcommand coloumn in this table.
