2.1.8 Analog Input Commands (Not Acknowledged)
DRIVE
Response
Com-
mand
Region NPA Object no. Attribu-
te No.
Attribute Message Type Error
Code Comments
NAK 1 1 0-23 4 Float Read Analog Input 11 1 ) Read Linear Ranging Parameter 1
attribute associated with each
individual point. (JCI use only)
NAK 1 1 0-23 5 Float Read Analog Input 11 1) Read Linear Ranging Parameter 2
attribute associated with each
individual point. (JCI use only)
NAK 2 - 0-23 2 Byte Write Analog Input 11 1) Object Status writeable
NAK 2 - 0-23 3 Float Write Analog Input 11 1) Analog Input Value not writeable
NAK 2 - 0-23 4 Float Write Analog Input 11 1) Write to Linear Ranging Parameter
1 attribute associated with each
individual point. (JCI use only)
NAK 2 - 0-23 5 Float Write Analog Input 11 1) Write to Linear Ranging Parameter
2 attribute associated with each
individual point. (JCI use only)
NAK 2 - 0-23 6 Float Write Analog Input 11 1) Write to Linear Ranging Parameter
3 attribute associated with each
individual point. (JCI use only)
NAK 2 - 0-23 7 Float Write Analog Input 11 1) Write to Linear Ranging Parameter
4 attribute associated with each
individual point. (JCI use only)
NAK 2 - 0-23 13 Integer Write Analog Input 11 1) Write to Filter Weight attribute as-
sociated with each individual point.
(JCI use only)
NAK 2 - 0-23 14 Float Write Analog Input 11 1) Write to AI Offset attribute associ-
ated with each
individual point. (JCI use only)
1) Error code 11 is used because attributes are considered as fields/records in the point map database.
Table 2.3: No Subcommand coloumn in this table.
