2.1.11 Binary Input (BI) Commands (Acknowledged)
DRIVE
Response
Command Subcom-
mand
Region NPA Object no. Attribute No. Attribute Message Type Comments
ACK 1 - 2 0-135 1 Byte Read Binary In-
put
Read Object Configuration at-
tribute associated with each
individual point
ACK 1 - 2 0-135 2 Byte Read Binary In-
put
Read Object Status attribute
associated with each individual
point
ACK 2 - 2 0-135 1 Byte Write Binary In-
put
Write to Object Configuration at-
tribute associated with each
individual point
ACK, no action 7 2 2 0-135 - Byte(0/1) Override Binary
Input
Binary inputs are "outputs" from
the frequency converter and
should not be written over by the
network controller. (Status word,
Warnings, and Alarms)
ACK, no action 7 3 2 0-135 - - OverrideRelease Binary inputs are "outputs" from
the drive and should not be writ-
ten over by the network control-
ler. (Status word, Warnings and
Alarms)
ACK, no action 7 7 2 0-135 - - Write Binary In-
put
Optional command for slave de-
vices. Only Attributes used for N2
commissioning purposes. Not to
be implemented at this time
ACK, no action 7 8 2 0-135 - - Read Binary In-
put
Optional command for Attrib-
utes slave devices. Only used for
N2 commissioning purposes. Not
to be implemented at this time
2.1.12 Binary Input (BI) Commands (Not Acknowledged)
DRIVE
Response
Command Region NPA Object no. Attribute No. Attribute Message Type Error Code Comments
NAK 2 2 0-135 2 Byte Write Binary In-
put
11 1 Object Status not writeable
NAK 2 2 0-135 3 Integer Write Binary In-
put
11 1 Write Debouncing Value in msec at-
tribute associated with each
individual point.(JCI use only)
NAK 2 2 0-135 4 Inte-
ger32
Write Binary In-
put
11 1 Write Accumulator value attribute
associated with each individual
point (JCI use only)
Table 2.6: No Subcommand coloumn in this table.
