2.2.1 Start-up of the Frequency Converter
Use the frequency converter keypad mounted either on the drive or remote. Use the Extended Menu key to access the O-## group parameters (Options / Comms).
The settings shown below are typical. Some settings may be changed to meet the application requirements. The settings below will serve as a good starting
reference. Refer to the operating instruction manual for instructions on changing parameters and programming the drive.
Examples of typical settings. Program the following:
Parameter: Setting:
par. O-30 Protocol [3] Metasys N2
par. O-31 Address 1 (Default)
par. O-32 Drive Port Baud Rate [2] 9600 Baud (fixed at 9600 for N2 protocol)
par. O-50 Coasting Select [3] Logic OR
par. O-52 DC Brake Select [3] Logic OR
par. O-53 Start Select [3] Logic OR
par. O-54 Reversing Select [0] Digital input
par. O-55 Set-up Select [3] Logic OR
par. O-56 Preset Reference Select [3] Logic OR
par. O-94 Bus Feedback 1 0
par. O-95 Bus Feedback 2 0
NB!
Send an F command to begin communications between the master and the drive!
Example 1:
F command Setting:
Device address XX
Char1 command F
Checksum YY
Message code:
>XXFYY Issue a run command through the master, to the device:
Example 2:
Network start, BO override command: Setting:
Device address XX
Char1 command 7
Char1 subcommand 2
Char2 region 04
Char2 object number (NPA) 04 (Start)
Char2 override value 01 (Active)
Checksum YY
Message code:
>XX72040401YY Issue a frequency reference through the master, to the device:
