2.1.13 Binary Output Commands (Acknowledged)
DRIVE
Response
Command
Subcom-
mand
Region NPA Object no.
Attribute No.
Attribute Message Type
Comments
ACK
1
-
4
0-10
1
Byte
Read Binary Output Read structure attributes associ-
ated with each individual point
ACK
1
-
4
0-10
2
Byte
Read Binary Output Read structure attributes associ-
ated with each individual point
ACK
2
-
4
0-10
1
Byte
Write Binary Output Write to Object Configuration at-
tribute associated with each
individual point
ACK
7
2
4
0-10
-
Byte(0/1) Override Binary Out-
put
Write to binary output current
state (Drive control word)
ACK
7
2
4
0-10
-
Byte(0/1) Override Binary Out-
put
Write to binary output current
state (Drive control word)
ACK
7
3
4
0-10
-
-
Override Release
Set the current value, the value
that it was before the 1. Override
Command was issued
ACK, no action
1
-
4
0-10
3
Integer
Read Binary Output Read Minimum On-time attribute
associated with each
individual point. Return value = 0
ACK, no action
1
-
4
0-10
4
Integer
Read Binary Output Read Minimum Off-time attribute
associated with each
individual point. Return value = 0
ACK, no action
1
-
4
0-10
5
Integer
Read Binary Output Read Maximum Cycles/ Hour at-
tribute associated with each
individual point. Return value = 0
ACK, no action
2
-
4
0-10
3
Integer
Write Binary Output Write Minimum On-time attribute
associated with each individual
point
ACK, no action
2
-
4
0-10
4
Integer
Write Binary Output Write Minimum Off-time attribute
associated with each individual
point
ACK, no action
2
-
4
0-10
5
Integer
Write Binary Output Write Maximum Cycles/ Hour at-
tribute associated with each
individual point
ACK, no action
7
7
4
0-10
-
-
Write Binary Output Optional command for slave de-
vices. Only Attributes used for N2
commissioning purposes
ACK, no action
7
8
4
0-10
-
-
Read Binary Output Optional command for slave de-
vices. Only Attributes used for N2
commissioning purposes
Table 2.7: No Error Code coloumn in this table.
2.1.14 Binary Output (BO) Commands (Not Acknowledged)
DRIVE
Response
Command
Region
NPA Object no.
Attribute No.
Attribute Message Type
Error Code
Comments
NAK
1
4
0-10
6
Integer Read Binary Out-
put
11
1)
Read Interstage on delay attribute
associated with each individual
point. (JCI use only)
NAK
1
4
0-10
7
Integer Read Binary Out-
put
11
1)
Read Interstage off delay attribute
associated with each individual
point. (JCI use only)
NAK
2
4
0-10
2
Byte
Write Binary Out-
put
11
1)
Object Status not writeable
NAK
2
4
0-10
6
Integer Write Binary Out-
put
11
1)
Write Interstage on delay attribute
associated with each individual
point. (JCI use only)
NAK
2
4
0-10
7
Integer Write Binary Out-
put
11
1)
Write Interstage off delay attribute
associated with each individual
point. (JCI use only)
1)
Error code 11 is used because attributes are considered as fields/records in the point map database.
Table 2.8: No Subcommand coloumn in this table.
