2.1.7 Analog Input Commands (Acknowledged)
DRIVE Re-
sponse
Command
Subcom-
mand
Region NPA Object no.
Attribute
No.
Attribute Message Type Comments
ACK 1 - 1 0-23 1 Byte Read Analog Input
Read Object Configuration at-
tribute associated with each
individual point
ACK 1 - 1 0-23 2 Byte Read Analog Input
1) Read Object Status attribute
associated with each
individual point
ACK 1 - 1 0-23 3 Float Read Analog Input
2) Read Analog Input Value at-
tribute associated with each
individual point
ACK 1 - 1 0-23 8 Float Read Analog Input
Read Low Alarm attribute as-
sociated with each
individual point
ACK 1 - 1 0-23 9 Float Read Analog Input
Read Low Warning attribute
associated with each
individual point
ACK 1 - 1 0-23 10 Float Read Analog Input
Read High Warning attribute
associated with each
individual point
ACK 1 - 1 0-23 11 Float Read Analog Input
Read High Alarm attribute as-
sociated with each
individual point
ACK 1 - 1 0-23 12 Float Read Analog Input
Read Differential attribute as-
sociated with each
individual point
ACK 2 - 1 0-23 1 Byte Write Analog Input
Write to Object Configuration
attribute associated with each
individual point
ACK 2 - 1 0-23 8 Float Write Analog Input
Write to Low Alarm Limit attrib-
ute associated with each
individual point
ACK 2 - 1 0-23 9 Float Write Analog Input
Write to Low Warning Limit at-
tribute associated with each
individual point
ACK 2 - 1 0-23 10 Float Write Analog Input
Write to High Warning Limitat-
tribute associated with each
individual point
ACK 2 - 1 0-23 11 Float Write Analog Input
Write to High Alarm Limit at-
tribute associated with each
individual point
ACK 2 - 1 0-23 12 Float Write Analog Input
Write to Differential attribute
associated with each
individual point
ACK, no action 7 2 1 0-23 - Float
Override Analog in-
puts
Analog inputs are "outputs"
from the frequency converter
and should not be written over
by the network controller
ACK, no action 7 3 1 0-23 - -
Override Analog Re-
lease
Analog inputs are "outputs"
from the frequency converter
and should not be written over
by the network controller
ACK, no action 7 7 1 0-23 - -
Write Analog Input
Attributes
Optional command for slave
devices. Only used for N2
commissioning purposes
Table 2.2: No Error code in this table.
