Binary Inputs (BI), continued..
NPT NPA UNIT DESCRIPTION SELECTION PAR. NUMBER
BI 136 - GPIO Terminal X30/4 0=FALSE , 1=TRUE DR-60
BI 150 -
ECB Manual Bypass
Override
0=FALSE , 1=TRUE BP-10
BI 151 - ECB External Interlock 0=FALSE , 1=TRUE BP-10
BI 152 - ECB M3 Contactor Fault 0=FALSE , 1=TRUE BP-10
BI 153 - ECB M2 Contactor Fault 0=FALSE , 1=TRUE BP-10
BI 154 - ECB Overload Trip 0=FALSE , 1=TRUE BP-10
BI 155 -
ECB Motor running from
Bypass/Drive
0=FALSE , 1=TRUE BP-10
BI 156 - ECB Reserved 0=FALSE , 1=TRUE BP-10
BI 157 - ECB Bypass Mode 0=FALSE , 1=TRUE BP-10
BI 158 -
ECB Automatic Bypass
Mode
0=FALSE , 1=TRUE BP-10
BI 159 - ECB Drive Mode 0=FALSE , 1=TRUE BP-10
BI 160 - ECB Test Mode 0=FALSE , 1=TRUE BP-10
The values marked in bold are default values
