3.1.2 Binary Inputs (BI)
NPT NPA UNIT DESCRIPTION RANGE PAR. NUMBER
BI 0 - Timers Status 0=OK , 1=Limit DR-03
BI 1 - Current Status 0=OK , 1=Limit DR-03
BI 2 - Voltage Status 0=OK , 1=Limit DR-03
BI 3 - Inverter Status 0=OK , 1 =Stall, Auto-start DR-03
BI 4 - Running Status 0=Not Running , 1=Running DR-03
BI 5 - Frequency Status 0=Out of Range , 1=In Range DR-03
BI 6 - Control Status 0=Local , 1= Bus DR-03
BI 7 - Reference Status 0=Not on Ref., 1=On Ref. DR-03
BI 8 - Warning Status 0=No Warning , 1= Warning DR-03
BI 9 - Tripped Status 0=No Trip , 1=Tripped DR-03
BI 10 - Drive Enabled Status 0=Not Enabled , 1=Enabled DR-03
BI 11 - Drive Ready Status 0=Not Ready , 1=Ready DR-03
BI 12 -
Drive Controller Sta-
tus
0=Not Ready , 1=Ready DR-03
BI 16 -
Auto tune suspicious
UNOM
0=OK , 1=Warning DR-92
BI 17 -
Auto tune suspicious
INOM
0=OK , 1=Warning DR-92
BI 18 -
Auto tune motor too
big
0=OK , 1=Warning DR-92
BI 19 -
Auto tune motor too
small
0=OK, 1=Warning DR-92
BI 20 - Frequency low 0=OK , 1=Warning DR-92
BI 21 - Frequency high 0=OK , 1=Warning DR-92
BI 22 - Current low 0=OK , 1=Warning DR-92
BI 23 - Profibus warning 0=OK , 1=Warning DR-92
BI 24 -
Output frequency
limited
0=OK , 1=Warning DR-92
BI 25 - Current high 0=OK , 1=Warning DR-92
BI 26 - Feedback low 0=OK , 1=Warning DR-92
BI 27 - Feedback high 0=OK , 1=Warning DR-92
BI 28 - Reference low 0=OK , 1=Warning DR-92
BI 29 - 10 Volt low 0=OK, 1=Warning DR-92
BI 30 - Live zero error 0=OK , 1=Warning DR-92
BI 31 - Phase loss 0=OK , 1=Warning DR-92
BI 32 - DC link voltage high 0=OK , 1=Warning DR-92
BI 33 - DC link voltage low 0=OK , 1=Warning DR-92
BI 34 - DC link over voltage 0=OK , 1=Warning DR-92
BI 35 - DC link under voltage 0=OK , 1=Warning DR-92
BI 36 - Drive thermal 0=OK , 1=Warning DR-92
BI 37 - Motor thermal 0=OK, 1=Warning DR-92
BI 38 - Motor thermistor 0=OK , 1=Warning DR-92
BI 39 - Current limit 0=OK , 1=Warning DR-92
BI 40 - Over current 0=OK , 1=Warning DR-92
BI 41 -
Standard bus time-
out
0=OK , 1=Warning DR-92
BI 42 - HPFB time-out 0=OK , 1=Warning DR-92
BI 43 -
EEPROM error power
card
0=OK , 1=Warning DR-92
Binary Inputs (BI), continued..
