3.1.3 PROFINET Cables
PROFINET cables used are based electrically on category 5 balanced LAN cables according to ISO/IEC 11801 Edition 2.0, Class
D.
Type C cables can be used in special applications (e.g. the use of trailing cables and frequently moved machine parts) even
though their design and mechanical parameters can deviate from the specifications of type A and type B cables. Still most
of the electrical parameters (impedance levels etc.) are retained. Highly flexible copper cables generally have the finest
stranded conductors and, for example, a highly resistant polyurethane outer sheath.
Various outer sheath materials are permitted in order to meet the various demands with regard to resistance of industrial
environments and exterior/underground laying (natural and synthetic oil, grease, coolants/lubricants, chemicals, high and
low temperatures, UV radiation).
All balanced cables used shall comply with the following parameters:
Cable Type Application Type A Application Type B Application Type C
Design Data Cable Data Cable Data Cable
Cable Installation Type Stationary, no movement
after installation
Flexible, occasional movement
or vibration
Special Applications (e.g. highly flexible,
permanent movement, vibration or torsion)
Cable Marking PROFINET Type A PROFINET Type B PROFINET Type C
Core Cross Section AWG 22/1 AWG 22/7 AWG 22/..
Outer Diameter 5,5 - 8,0 mm Application
Core Diameter 1,5 +/- 0,1 mm Application
Colour (Outer Sheath) Green RAL6018 Application
Core Identification (colours) star
quad 2 pair
white, yellow, blue, orange Pair 1: white (RXD+), blue (RXD-) Pair 2: yellow(TXD+), orange(TXT-)
Number of Cores 4
Cable Design 2 pairs or 1 star quad
Shielding Design Type Aluminum Foil + Cu braiding Application
Which Plug for which Cable Type RJ45 (IP 20 or IP 65/67) / M12
Table 3.1
Transmission Performance Requirements:
Relevant Standard ISO/IEC 11801 Edition 2.0, IEC 61156
(minimum Category 5)
Delay Skew <=20ns/100m
Transfer Impedance <=50mOhm/m at 10MHz
Table 3.2
