O-90 Bus Jog 1 Speed
Range: Function:
100 RPM * [0 - par. F-17
RPM]
Enter the jog speed. This is a fixed
jog speed activated via the serial
port or network option.
O-91 Bus Jog 2 Speed
Range: Function:
200 RPM * [0 - par. F-17
RPM]
Enter the jog speed. This is a fixed
jog speed activated via the serial
port or network option.
8.2 Parameter Group PB-## PROFIdrive
PB-15 PCD Write Configuration
Array [10]
Option: Function:
Select the parameters to be assigned to PCD 3 to 10 of
the messages. The number of available PCDs depends
on the telegram type. The values in PCD 3 to 10 will
then be written to the selected parameters as data
values. Alternatively, specify a standard Profibus
message in PB-22 Telegram Selection.
PB-16 PCD Read Configuration
Array [10]
Option: Function:
Select the parameters to be assigned to PCD 3 to 10 of
the messages. The number of available PCDs depends
on the telegram type. PCDs 3 to 10 contain the actual
data values of the selected parameters. For standard
Profibus message, see PB-22 Telegram Selection.
PB-22 Telegram Selection
Option: Function:
Select a standard Profibus telegram
configuration for the frequency
converter, as an alternative to
using the freely configurable
telegrams in PB-15 PCD Write
Configuration and PB-16 PCD Read
Configuration.
[1] Standard telegram 1
[100] None
[101] PPO 1
[102] PPO 2
[103] PPO 3
[104] PPO 4
[105] PPO 5
[106] PPO 6
[107] PPO 7
[108] * PPO 8
[200] Custom telegram 1
[202] Custom telegram 3
PB-23 Parameters for Signals
Array [1000]
Option: Function:
This parameter contains a list of signals available for
selection in PB-15 PCD Write Configuration and
PB-16 PCD Read Configuration.
PB-27 Parameter Edit
Option: Function:
Parameters can be edited via PROFINET, the
standard RS485 interface, or the keypad.
[0] Disabled Disables editing via PROFINET.
[1] * Enabled Enables editing via PROFINET.
PB-28 Process Control
Option: Function:
Process control (setting of Control Word, speed
reference, and process data) is possible via
either PROFINET or standard Network but not
both simultaneously. Local control is always
possible via the keypad. Control via process
control is possible via either terminals or
Network depending on the settings in
O-50 Coasting Select to O-56 Preset Reference
Select.
[0] Disable Disables process control via PROFINET, and
enables process control via standard Network or
PROFINET IO-Supervisor.
[1] * Enable
cyclic
master
Enables process control via IO Controller, and
disables process control via standard Network or
PROFINET IO-Supervisor..
PB-53 Profibus Warning Word
Range: Function:
0 N/A * [0 - 65535 N/A] This parameter displays PROFINET
communication warnings. Please refer
to the PROFINET Operating Instructions
for further information.
Read only
