8.4 PROFINET-specific Parameter List
Parameter Default value Range Conver-
sion index Data type
O-01 Control Site Dig. & ctrl. word [0] [0 - 2] - Uint8
O-02 Control Word Source Drive RS485 [0] [0 - 4] - Uint8
O-03 Control Word Timeout Time 1 0.1-18000 -1 Uint32
O-04 Control Word Timeout Function Off [0] [0 - 10] - Uint8
O-05 End-of-Timeout Function Hold set-up [0] [0 - 1] - Uint8
O-06 Reset Control Word Timeout Do not reset [0] [0 - 1] - Uint8
O-07 Diagnosis Trigger Disable [0] [0 - 3] - Uint8
O-10 Control Word Profile GE Drive profile [0] [0 - x] - Uint8
O-13 Configurable Status Word STW
O-50 Coasting Select *Logic OR [3] [0 - 3] - Uint8
O-51 Quick Stop Select *Logic OR [3] [0 - 3] - Uint8
O-52 DC Brake Select *Logic OR [3] [0 - 3] - Uint8
O-53 Start Select *Logic OR [3] [0 - 3] - Uint8
O-54 Reversing Select *Logic OR [3] [0 - 3] - Uint8
O-55 Set-up Select *Logic OR [3] [0 - 3] - Uint8
O-56 Preset Reference Select *Logic OR [3] [0 - 3] - Uint8
O-90 Bus Jog 1 Speed 100 rpm
0 - F-17 Motor Speed High
Limit [RPM] 67 Uint16
O-91 Bus Jog 2 Speed 200 rpm
0 - F-17 Motor Speed High
Limit [RPM] 67 Uint16
PB-15 PCD Write Configuration - - - Uint16
PB-16 PCD Read Configuration - - - Uint16
PB-22 Telegram Selection - [0 - 108] - Uint8
PB-23 Parameters for Signals - 0 - 573 - Uint16
PB-27 Parameter Edit Enabled [1] [0 - 1] - Uint16
PB-28 Process Control Enable cyclic master [1] [0 - 1] - Uint16
PB-44 Fault Message Counter 0 [0 - 8] 0 Uint16
PB-45 Fault Code 0 - - Uint16
PB-47 Fault Number 0 - - Uint16
PB-52 Fault Situation Counter 0 0 - 1000 0 Uint16
PB-53 Profibus Warning Word 0 16 bits 0 V2
PB-64 Device Identification 0 [0 - 10] 0 Uint16
PB-65 Profile Number 0 8 bits 0 Uint8
PB-70 Edit Set-up Active set-up [9] [0 - 9] - Uint8
PB-71 Profibus Save Data Values Off [0] [0 - 2] - Uint8
PB-72 ProfibusDriveReset No action [0] [0 - 2] - Uint8
PB-80 Defined Parameters (1) - 0-115 0 Uint16
PB-81 Defined Parameters (2) 0-115 0 Uint16
PB-82 Defined Parameters (3) - 0-115 0 Uint16
PB-83 Defined Parameters (4) - 0-115 0 Uint16
PB-90 Changed Parameters (1) - 0-115 0 Uint16
PB-91 Changed Parameters (2) - 0-115 0 Uint16
PB-92 Changed Parameters (3) - 0-115 0 Uint16
PB-93 Changed parameters (4) - 0-115 0 Uint16
EN-00 IP Address Assignment 0.0.0.0 0 - 255 - Unsigned 8
EN-01 IP Address 0.0.0.0 0 - 255 - Oct. string 4
EN-02 Subnet Mask 0.0.0.0 0 - 255 - Oct. string 4
EN-03 Default Gateway 0.0.0.0 0 - 255 - Oct. string 4-
EN-04 DHCP Server 0.0.0.0 0 - 255 - Oct. string 4
