Page 3: Feature specifications

GE
Data Sheet
CAR2012TE series rectifier
Input: 85Vac to 264Vac; Output: 12 Vdc @ 2000W; 3.3Vdc or 5 Vdc @ 4A
February 9, 2014
©2013 General Electric Company. All rights reserved.
Page 3
12V
dc
MAIN OUTPUT (continued)
Parameter
Symbol
Min
Typ
Max
Unit
Ripple and noise
2
at 25C, ( relaxed to 150mV
P-P
below 0C)
120 mV
P-P
Turn-ON overshoot
+3
%
Turn-ON delay
T
2
sec
Remote ON/OFF delay time
40 ms
Turn-ON rise time (10 – 90% of V
out
)
50 ms
Transient response 50% step [10%-60%, 50% - 100%]
(dI/dt – 1A/µs, recovery 300µs)
V
O
-5 +5 %V
O
Programmable range (hardware & software)
10.8
13.2
V
DC
Overvoltage protection, latched
(recovery by cycling OFF/ON via hardware or software)
13.8 14.8 15.8
V
DC
Output current 180 ≥ V
IN
≥ 264
90 ≥ V
IN
≥ 132
I
O
0
167
108
A
DC
Current limit, Hiccup (programmable level)
110
130
% of FL
Active current share, ( I
O
≥ 20% of I
O,MAX
)
-5
+5
% of FL
STANDBY OUTPUT
Parameter
Symbol
Min
Typ
Max
Unit
Set point
V
O
3.3 / 5.0
V
DC
Overall regulation (load, temperature, aging)
V
O
-5
+5
%
Ripple and noise, STANDBY
CLOCK – I
2
C
DATA – I
2
C
100 mV
P-P
Output current [3.3V / 5V]
I
O
0 4
/
3 A
DC
Overload protection -
110
150
% of FL
Isolation Output/Frame
100
V
DC
General Specifications
Parameter
Min
Typ
Max
Units
Notes
Reliability, 25C
50C
320,000
100,000
Hrs
Full load, ; MTBF per SR232 Reliability protection for
electronic equipment, method I, case III,
Service Life
10
Yrs
Full load, excluding fans
Weight
Feature Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature conditions. See
Feature Descriptions for additional information.
Parameter
Symbol
Min
Typ
Max
Unit
Remote ON/OFF (pulled up internally within the module)
Logic High (Module ON)
0.7V
STDBY
V
STDBY
V
DC
Logic Low (Module OFF)
I
IL
1 mA
V
IL
0
0.8 V
DC
2
Measured across a 10µf tantalum and a 0.1µf ceramic capacitors in parallel. 20MHz bandwidth
