Arc Vault™ Protection System
Post Event Procedure
© 2011 General Electric All Rights Reserved
35
SECTION 10.
POST EVENT PROCEDURE
If a short circuit event triggers the Arc Vault device and
opens the upstream breaker, perform these steps.
1. Verify upstream breaker has tripped and is open.
2. Check the event indicator light (amber color) in the top
instrument tray. It should be illuminated.
3. If illuminated, an event has occurred and the Arc Vault
device needs to be replaced.
4. Call GE Engineering field services at 888-GE4-SERV
(888-434-7378) or GE Resolve at 888-437-3765and
report an arcing event occurred and an Arc Vault was
installed. Order a replacement Arc Vault device catalog
# GAVDR1.
5. Verify that the arc fault has been cleared.
6. Rack out the Arc Vault device. Refer to SECTION 5.
7. Replace the new Arc Vault device by following the
previous steps in SECTION 5, 6, and 7.
8. Reset the Arc Vault 86 lockout device.
WARNING
Until the new device is installed, full protection is not
available. Relay only protection is available when
resetting the 86 lockout device.
