9.4.2 Input Variables (nvi)
Variable Function Variable Name SNVT type Profile AF-600 FP Par.
Start/Stop nviStartStop SNVT_switch Drive VSD CTW/reference
Control word nviControlword SNVT_state Drive VSD CTW
Reset fault nviResetFaut SNVT_switch Drive VSD CTW
Reference [%] nviRefPcnt SNVT_lev_percent Drive VSD Reference
Reference [Hz] nviRefHz SNVT_freq_hz Drive VSD Reference
CL Setpoint 1 nviSetpoint1 SNVT_lev_percent Drive VSD CL-21
CL Setpoint 2 nviSetpoint2 SNVT_lev_percent Drive VSD CL-22
CL Setpoint 3 nviSetpoint3 SNVT_lev_percent Drive VSD CL-23
Bus feedback 1 nviFeedback1 SNVT_lev_percent Drive VSD O-94
Bus feedback 2 nviFeedback2 SNVT_lev_percent Drive VSD O-95
Bus feedback 3 nviFeedback3 SNVT_lev_percent Drive VSD O-96
Digital/relay outputs nviDigiOutput SNVT_state_64 Drive VSD E-90
Analog output (42) nviAnOut1 SNVT_lev_percent Drive VSD AN-53
Analog output (X30/8) nvi101AnOut1 SNVT_lev_percent Drive VSD AN-63
Analog output (X42/7) nvi109AnOut1 SNVT_lev_percent Drive VSD AO-43
Analog output (X42/9) nvi109AnOut2 SNVT_lev_percent Drive VSD AO-53
Analog output (X42/11) nvi109AnOut3 SNVT_lev_percent Drive VSD AO-63
Setting of RTC nviTimeStamp SNVT_time_stamp Drive VSD K-70
Parameter access command nviParamRequest UNVT_param_request Drive VSD -
Drive speed setpoint nviDrvSpeedStpt SNVT_switch VSD 6010 CTW / Reference
Standard Node Object nviRequest SNVT_obj_request Node obj. -
9.4.3 Configuration Properties (nci)
Variable function Variable name SNVT type Profile
AF-600 FP
Par.
Max. motor speed [%] nciMaxSpeed SNVT_lev_percent VSD 6010 F-17
Min. motor speed [%] nciMinSpeed SNVT_lev_percent VSD 6010 F-18
Nom. motor speed [RPM] nciNmlSpeed SNVT_rpm VSD 6010 P-06
Nom. motor frequency [Hz] nciNmlFreq SNVT_freq_hz VSD 6010 F-04
Min. ramp-up time [s] nciRampUpTime SNVT_time_sec VSD 6010 F-07
Min. ramp-down time [s] nciRampDownTime SNVT_time_sec VSD 6010 F-08
Heartbeat time [s] nciSndHrtBt SNVT_time_sec VSD 6010 -
Max Send Time (Heartbeat) nciMaxStsSendT SNVT_elapsed_tm Node obj. -
Min Send Time (Inhibit timer) nciMinSendT SNVT_elapsed_tm Virtual obj. -
