5.2.2 Network Variable Description - Drive VSD Profile - Output
Status Word
Variable name: SNVT type: State:
nvoStatusWord SNVT_state Boolean 1 bit x 16
This variable is a 16-bit word providing status information on the frequency converter. For more information on the status word, please refer to the GE Drive
Control Profile section.
NB!
Please note that in the representation of the Status Word in the LonMaker Browser, the Least Significant Bit (LSB) is to the far left.
Drive Output [%]
Variable
name: SNVT
type:
Value:
nvoOutputPcnt SNVT_lev_percent Min. Max. Resolution:
-163.840 % +163.840 % 0.005 %
In open loop operation, this variable contains the frequency converter output frequency in percentage, within the reference range.
In closed loop operation, this variable contains the frequency converter feedback signal, within the reference range.
Drive Output [Hz]
Variable
name: SNVT
type:
Value:
nvoOutputHz SNVT_freq_hz Min. Max. Resolution:
0 Hz 6,500 Hz 1 Hz
This variable displays the actual output of the frequency converter motor frequency in Hz.
kWh Counter [kWh]
Variable
name: SNVT
type:
Value:
nvoDrvEnrg SNVT_elec_kwh_l Min. Max. Resolution:
0 kWh 219,748,364.8 kWh 1 kWh
This variable contains the power consumption of the motor in kWh measured as a mean value over a one hour period.
