6 How to Control the Drive
6.1 How to Control the AF-600 FP
6.1.1 Reference Handling
Select the frequency converter configuration mode in par. H-40 Configuration Mode.
[0] Open Loop
[3] Closed Loop
6.1.2 Open Loop
For open loop operation, the reference represents the desired output speed of the frequency converter.
The speed reference value is transmitted to the frequency converter as a relative value in %.
6.1.3 Closed Loop
In closed loop operation the feedback/reference is scaled from 1 to par. CL-14 Maximum Reference/Feedb..
par. F-16 par. F-15 par. F-03
par. CL-14
