9.4 Network Variables - Overview
9.4.1 Output Variables (nvo)
Variable function Variable name SNVT type Profile AF-600 FPpar.
Status word nvoStatusword SNVT_state Drive VSD DR-03
Drive output [%] nvoOutputPcnt SNVT_lev_percent Drive VSD DR-05
Drive output [Hz] nvoOutputHz SNVT_freq_hz Drive VSD DR-13
kWh counter nvoDrvEnrg SNVT_elec_kwh_l Drive VSD ID-02
DC Link Voltage nvoDCVoltage SNVT_volt Drive VSD DR-30
Motor thermal nvoTempMtr SNVT_lev_cont Drive VSD DR-18
Inverter Thermal nvoTempInvrtr SNVT_lev_cont Drive VSD DR-35
Closed loop feedback nvoFeedback SNVT_count_inc_f Drive VSD DR-52
Fanbelt broken nvoBrokenBelt SNVT_switch Drive VSD DR-93
Alarm flag nvoAlarm SNVT_switch Drive VSD DR-90
Warning flag nvoWarning SNVT_switch Drive VSD DR-03
Alarm word nvoAlarmword SNVT_state_64 Drive VSD DR-90 + DR-91
Warning word nvoWarningword SNVT_state_64 Drive VSD DR-92 + DR-93
Extended statusword nvoExtendedStatusword SNVT_state_64 Drive VSD DR-94 + DR-95
Digital inputs nvoDigitInput SNVT_state_64 Drive VSD DR-60
Analog Input (53) nvoAnIn1 SNVT_volt/SNVT_amp_mil/SNVT_lev_percent Drive VSD DR-62
Analog Input (54) nvoAnIn2 SNVT_volt/SNVT_amp_mil/SNVT_lev_percent Drive VSD DR-64
Analog Input (X30/11) nvo101AnIn1 SNVT_volt/SNVT_lev_percent Drive VSD DR-75
Analog Input (X30/12) nvo101AnIn2 SNVT_volt/SNVT_lev_percent Drive VSD DR-76
Analog Input (X42/1) nvo109AnIn1 SNVT_volt/SNVT_temp_p/SNVT_lev_percent Drive VSD LG-30
Analog Input (X42/3) nvo109AnIn2 SNVT_volt/SNVT_temp_p/SNVT_lev_percent Drive VSD LG-31
Analog Input (X42/5) nvo109AnIn3 SNVT_volt/SNVT_temp_p/SNVT_lev_percent Drive VSD LG-32
Parameter access cmd. nvoParamResponse UNVT_param_response Drive VSD -
Drive Speed nvoDrvSpeed SNVT_lev_percent VSD 6010 DR-05
Output current nvoDrvCurnt SNVT_amp VSD 6010 DR-14
Output voltage nvoDrvVolt SNVT_volt VSD 6010 DR-12
Output power nvoDrvPwr SNVT_power_kilo VSD 6010 DR-10
Running hours nvoDrvRunHours SNVT_time_hour VSD 6010 ID-01
Object Status nvoStatus SNVT_obj_status Node obj. -
