Analog Input (54)
Variable
name: SNVT
type:
Value:
nvoAnIn1 Changeable Min. Max. Resolution:
SNVT_volt 0 V 10 V 0.1 V
SNVT_amp_mil 0 mA 20 mA 0.1 mA
SNVT_lev_percent 0 % 100 % 0,1 %
This variable contains the value allocated to the analog input terminal 54.
This terminal can either be configured as a voltage input (0-10 V) or as a current input (0-20 mA), depending on the setting of switch S 202. The variable type is
changeable with the commissioning tool in order to match the appropriate unit.
If the variable type of SNVT_lev_percent is selected, the relative scaling is from 0 V/mA to par. AN-21 Terminal 54 High Voltage or par. AN-23 Terminal 54 High
Current
Analog Input (X30/11)
Variable
name: SNVT
type:
Value:
nvo101AnIn1 Changeable Min. Max. Resolution:
SNVT_volt 0 V 10 V 0.1 V
SNVT_lev_percent 0 % 100 % 0,1 %
This variable contains the value allocated to the analog input terminal X30/11 of the (OPCGPIO) General Purpose I/O Option Module.
If the variable type of SNVT_lev_percent is selected, the relative scaling is from 0 V to par. AN-31 Terminal X30/11 High Voltage.
NB!
This variable is available only if the General Purpose I/O Option Module (OPCGPIO) has been installed in the frequency converter.
Analog Input (X30/12)
Variable
name: SNVT
type:
Value:
nvo101AnIn2 Changeable Min. Max. Resolution:
SNVT_volt 0 V 10 V 0.1 V
SNVT_lev_percent 0 % 100 % 0,1 %
This variable contains the value allocated to the analog input terminal X30/12 of the OPCGPIO General Purpose I/O Option Module.
If the variable type of SNVT_lev_percent is selected, the relative scaling is from 0 V to par. AN-41 Terminal X30/12 High Voltage.
NB!
This variable is available only if the General Purpose I/O Option Module (OPCGPIO) has been installed in the frequency converter.
