Digital / Relay Outputs
Variable
name:
SNVT
type:
State:
nviDigitOutput
SNVT_state_64
Boolean 1 bit x 64
This variable controls the state of the digital outputs and relays.
A logical 1, indicates that the output is On or active.
A logical 0, indicates that the output is Off or inactive.
Bit 0
CC Digital Output Terminal 27
Bit 1
CC Digital Output Terminal 29
Bit 2
OPCGPIO field installed option module - Digital Output Terminal X30/6
Bit 3
OPCGPIO field installed option module - Digital Output Terminal X30/7
Bit 4
CC Relay 1 output terminal
Bit 5
CC Relay 2 output terminal
Bit 6
OPCRLY field installed option module - Relay 1 output terminal
Bit 7
OPCRLY field installed option module - Relay 2 output terminal
Bit 8
OPCRLY field installed option module - Relay 3 output terminal
Bit 9-63
Reserved for future terminals
Analog Output (42)
Variable
name:
SNVT
type:
Value:
nviAnOut1
SNVT_lev_percent
Min.:
Max.:
Resulution:
0 %
100 %
0.01 %
This variable controls the analog output 42, 0-20 mA or 4-20 mA.
In order to control analog output term#42 via LonWorks, par. AN-50 Terminal 42 Output must be set to one of the following options:
[139] Bus ctrl. 0-20 mA
[140] Bus crtl. 4-20 mA
[141] Bus crtl. 0-20 mA Timeout
[142] Bus crtl. 4-20 mA Timeout
Function:
Bus crtl. 0-20 mA [139]: The output is controlled via bus. In the event of bus timeout, the output level remains unchanged.
Bus crtl. 4-20 mA [140]: The output is controlled via bus. In the event of bus timeout, the output level remains unchanged.
Bus crtl. 0-20 mA [141]: The output is controlled via bus. In the event of bus timeout, the output level is set to the predefined level in par. AN-54 Terminal 42 Output
Timeout Preset.
Bus crtl. 4-20 mA [142]: The output is controlled via bus. In the event of bus timeout, the output level is set to the predefined level in par. AN-54 Terminal 42 Output
Timeout Preset.
