ESR90x Technical Data
Manual Documentation Number: ESR90x-5012m Chapter 12 67
B&B Electronics Mfg Co Inc – 707 Dayton Rd - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
Default Server
Settings Server Name ESR901 or ESR902 or ESR904
Serial Number: xxxxxxxxx (printed on bottom of unit)
Password: Blank
DHCP: Disable
IP Address: 192.168.0.1
Net Mask: 255.255.255.0
Gateway: 192.168.0.254
MAC Address: Fixed – see bottom label
Version&Date: current firmware version number & date
Serial server port: 1
Baud Rate: 9600
Data//Stop: 8-1
Parity: None
Flow Control: None
TCP/UDP Protocol: ESR901 serial port: TCP
ESR902 Ports 1 & 2: TCP
ESR902 Ports 1, 2, 3 & 4: TCP
Serial timeout: 0 seconds
TCP alive timeout: 0 minutes
Connection Mode: Server
Delimiter HEX 1: 00
Delimiter HEX 2: 00
Force transmit: 0 ms
TCP/UDP port: ESR901/902/904 Port 1: 4000
ESR902/904 Port 2: 4001
ESR904 Port 3: 4002
ESR904 Port 4: 4003
Serial port mode: ESR901/902/904 (all ports): RS-232
Max connection: 1
Remote IP Address: 255.255.255.255
DIP switch settings: ESR901: 1 = Run
2 = DB9
ESR902: Run
ESR904: Run
