Making the Hardware Connections
16 Chapter 2 Manual Documentation Number: ESR90x-5012m
B&B Electronics Mfg Co Inc – 707 Dayton Rd - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
J13
J22
J17
J9
J7 J21
J3 J2
J14 J28
J20 J8
J12 J27
J26 J11
J6 J19
J5 J18
J10 J25
J16 J24
Figure 10. ESR904 Bias Jumper Locations
