Using Console Mode
Manual Documentation Number: ESR90x-5012m
Chapter 9
53
B&B Electronics Mfg Co Inc – 707 Dayton Rd - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
C
C
h
h
a
a
p
p
t
t
e
e
r
r
9
9
:
:
U
U
S
S
I
I
N
N
G
G
C
C
O
O
N
N
S
S
O
O
L
L
E
E
M
M
O
O
D
D
E
E
Before the
Serial Server
is installed on a LAN the
Console Mode
can be
used to change the settings from the defaults. The Serial Server is shipped in
the
RS-232 Mode
.
Connect a crossover (null modem) cable between the
COM port on the computer and the appropriate serial port on the
Serial
Server.
N
N
o
o
t
t
e
e
:
:
See Chapter 5 for details of each Server Property Settings.
Console Mode Setup
Step 1: Apply power to the Serial Server. The power and ready LED will
light.
Step 2: Using
a
VT100
Terminal
emulation
program
(typically
HyperTerminal
in Windows) open the computer COM port
connected to the Serial Server (via an RS-232 crossover cable).
Step 3: In the HyperTerminal
Port Settings
window set:
o Baud rate: 9600
o Data bits: 8
o Parity: None
o Stop bits: 1
o Flow control: None
Click
OK
Step 4: Ensure the
Run/Console
switch is in the
Console
position.
Step 5: To view the
Configuration Menu
, press the
space bar
. The menu
will appear within a few seconds.
