ESR90x Technical Data
66
Chapter 12
Manual Documentation Number: ESR90x-5012m
B&B Electronics Mfg Co Inc – 707 Dayton Rd - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
DC Power:
Removable four terminal screw-type terminal block
Serial Interfaces
RS-232(DTE):
TXD, RXD, RTS, CTS, DTR, DSR, DCD, GND
(ESR901 Terminal block option: TXD, RXD, RTS,
CTS, GND)
RS-422:
TXDB(+), TXDA(−), RXDB(+), RXDA(−),
RTS(+), RTS(−), CTS(+), CTS(−) and GND
(ESR901 Terminal block option: (TXDB(+),
TXDA(−), RXDB(+), RXDA(−), GND)
RS-485 H:
Data B (+), Data A (–) and GND
RS-485F:
TXDB(+), TXDA(−), RXDB(+), RXDA(−),
and GND
(ESR901 Terminal block option: (TXDB(+),
TXDA(−), RXDB(+), RXDA(−), GND)
Baud Rate:
110 bps to 230.4 k bps
Parity:
None, Even, Odd, Mark, Space
Data Bits:
5, 6, 7 or 8
Stop Bits:
1, 1.5 or 2
Memory
Serial Memory:
8K byte per port
Network Memory:
48K byte
I/P Port Addresses
5300
Heartbeat & Configuration setting in TCP Mode (i.e.
Pair Mode)
8888
Vlinx update
8890
Vlinx monitor
8889
Set configuration in UDP mode
Network
Communications
LAN:
10/100 Mbps Auto-detecting 10 BaseT or 100
BaseTX
Protocols
TCP, IP, ARP, DHCP, Telnet, HTTP, UDP, ICMP
Configuration
Options
Console Mode:
Using RS-232 with VT100 emulation
Telnet Mode:
Using HyperTerminal with VT100 emulation
ESP Manager:
Using Windows 2000, XP, Server 2003, Vista,
Server 2008 & Windows 7
Web Server:
Using Internet Explorer web browser
Optional
Accessories
232NM9 Null Modem Crossover Cable for DTE to DTE connection
ERS35 one-meter length of steel 35mm DIN Rail
