GW-7553 PROFIBUS/Modbus TCP Gateway User Manual (Version 1.00, Dec/2008) PAGE: 69

utton to show safe value setting of DO/AO, click

(6) Display and Save interface
The user can click “Output” b
“Input” button to show safe value setting of DI/AI, click “Save to File” button to
open “save file dialog” to save safe value setting for backup, click “Save to
Device” button to save safe value setting to EEPROM of the GW-7553.

Figure 70 Safe value setting

5.5 IP setting

f IP setting. They are (1) Open a new setting、(2)Load from

Figure 71 The menu of IP setting

There are 3 kinds o
file、(3)Load from device, as shown in figure 71.
