GW-7553 PROFIBUS/Modbus TCP Gateway User Manual (Version 1.00, Dec/2008) PAGE: 32
●
Input module：Input Relay/Coil => 1~32 Bytes
Input Register => 1~64 Words
●
Max. length of I/O data：259 Bytes
●
Output length：0~131 Bytes
●
Input length：0~128 Bytes
The modules have module parameters about the communication settings. The
module parameters are shown in the below：
A. Output Relay/Coil module parameters：
●
Modbus Slave Device ID(M)：0~247
●
Start Address(M)：0~65535
●
NO. of Relay/Coil(M)：8*(n-1)+1 ~ 8*n Bits
n=Module size/Byte
●
TCP_Connect_Index(T)(M)：1~8
B. Output Register module parameters：
●
Modbus Slave Device ID (M)：0~247
●
Start Address(M)：0~65535
●
TCP_Connect_Index(T)(M)：1~8
C. Input Relay/Coil module parameters：
●
Modbus Slave Device ID (M)：0~247
●
Start Address(M)：0~65535
●
NO. of Relay/Coil(M)：8*(n-1)+1 ~ 8*n Bits
●
Module Type(M)：Read DI/DO
n=Module size/Byte
●
TCP_Connect_Index(T)(M)：1~8
D. Input Register module parameters：
●
Modbus Slave Device ID (M)：0~247
●
Start Address(M)：0~65535
●
Module Type(M)：Read AI/AO
●
TCP_Connect_Index(T)(M)：1~8
Example 1:
If the user wants to read a Modbus digital input module (DI module), Device ID is
1, data address is 10010~10019, and data count is 10 via the first TCP connection.
In this case, the user can select an “Input Relay/Coil=> 2 Bytes module”, module
parameters are shown in the below:
