GW-7553 PROFIBUS/Modbus TCP Gateway User Manual (Version 1.00, Dec/2008) PAGE: 6
●
Baud Rate：2400/4800/9600/19200/38400/57600/115200 bps
●
Data Format: 7/8 data bits, None/Odd/Even parity bit, 1/2 stop bit
PROFIBUS specs:
●
PROFIBUS interface connector: D-Sub 9-pin female
●
Baud Rate: 9.6k/19.2k/45.45k/93.75k/187.5k/500k/1.5M/3M/6M/12Mbps
●
Address Setting: 0~126 (set by DIP switch or EEPROM)
Ethernet specs:
●
10/100Base-TX (Auto-negotiating, Auto_MDIX, LED indicator)
Power requirement:
●
Unregulated +10 ~ +30 V
DC
●
Power reverse protection, Over-Voltage brown-out protection
●
Power consumption 2.5W
Module specs:
●
Dimensions: 119mm x 72mm x 33mm
●
Operating temperature: -25 ~ 75 ºC
●
Storage temperature: -30 ~ 85 ºC
●
Humidity：5 ~ 95% RH, non-condensing
●
LED Status Indicators(Table 2)
Table 2: LED status indicator
PWR LED
− Show the power state
− Show data state
ERR LED − Show error state
RUN LED − Show communication state of PROFIBUS
