GW-7553 PROFIBUS/Modbus TCP Gateway User Manual (Version 1.00, Dec/2008) PAGE: 64
3. Safe Value Setting =>
a. New Setting：Open a new safe value setting.
b. Load from file：Load a safe value setting from the file.
c. Load from device：Load a safe value setting from the GW-7553.
4. View =>
a. Space configuration in device：Display memory address configuration
of select module in the GW-7553.
b. Space configuration in PROFIBUS：Display memory address
configuration of select module in PROFIBUS Master station.
c. Space configuration in Modbus：Display memory address
configuration of select module in the Modbus.
5. Help =>
a. Get Firmware Version From Module：Show firmware version of the
GW-7553.
b. About Utility：Show about version of the utility.
5.2.2 COM Port settings：
1. Port: COM1~COM8
2. Baud rate: 2400/4800/9600/19200/38400/57600/115200
3. Parity: None/Odd/Even
4. Data bit: 8 data bit
5. Stop bit: 1 stop bit
5.2.3 Module state：
It can display the number of modules in the GW-7553 and display module
parameters in the window of the module parameter by click the module’s icon.
5.2.4 Module parameters：
Display module parameters of the GW-7553.
5.2.5 Connection status of device and COM Port：
Module state：Display connection status between the utility and the GW-7553.
The green color means connected and the red color means
disconnected.
COM Port state：Display state of the PC’s COM Port. The green color means
COM Port is open and the red color means COM Port is close.
