DS2182A

041995 9/22

RIMR1: RECEIVE INTERRUPT MASK REGISTER 1 Figure 9

(MSB)

(LSB)

8ZD

16ZD

RCL

RYEL

RLOS

B8ZSD

RBL

COFA

SYMBOL

POSITION

NAME AND DESCRIPTION

8ZD

RIMR1.7

8 Zero Detect Mask.
1 = interrupt enabled
0 = interrupt masked

16ZD

RIMR1.6

16 Zero Detect Mask.
1 = interrupt enabled
0 = interrupt masked

RCL

RIMR1.5

Receive Carrier Loss Mask.
1 = interrupt enabled
0 = interrupt masked

RYEL

RIMR1.4

Receive Yellow Alarm Mask.
1 = interrupt enabled
0 = interrupt masked

RLOS

RIMR1.3

Receive Loss Of Sync Mask.
1 = interrupt enabled
0 = interrupt masked

B8ZSD

RIMR1.2

B8ZS Code Word Detect Mask.
1 = interrupt enabled
0 = interrupt masked

RBL

RIMR1.1

Receive Blue Alarm Mask.
1 = interrupt enabled
0 = interrupt masked

COFA

RIMR1.0

Change Of Frame Alignment Mask.
1 = interrupt enabled
0 = interrupt masked
