DS2182A
041995 14/22
193E RECEIVE MULTIFRAME TIMING Figure 15
ЙЙЙЙЙЙ
ЙЙЙЙЙЙ
1
2
3
4
5
6
7
8
9
10 11
12
13 14
15
16 17
FRAME#
RFSYNC
RMSYNC
RSIGSEL
RSIGFR
RLCLK
RABCD
RLINK
ЙЙЙЙЙ
ЙЙЙЙЙ
ЙЙЙЙЙЙ
ЙЙЙЙЙЙ
ЙЙЙЙЙ
ЙЙЙЙЙ
ЙЙ
ЙЙ
D
A
C
B
D
18 19
20
21
22
23 24
NOTES:
1. Signaling data is updated during signaling frames on channel boundaries. Pin RABCD is the LSB of each
channel word in non-signaling frames.
2. RLINK data (FDL data) is updated one bit-time prior to odd frames and held for two frames.
