Table 29. TL2 Register

TL2 (S:CCh)
Timer 2 Low Byte Register

Reset Value = 0000 0000b
Not bit addressable

Table 30. RCAP2H Register

RCAP2H (S:CBh)
Timer 2 Reload/Capture High
Byte Register

Reset Value = 0000 0000b
Not bit addressable

Table 31. RCAP2L Register

RCAP2L (S:CA

H

)

T

IMER

2 R

E

load/Capture Low

Byte Register

Reset Value = 0000 0000b
Not bit addressable

7

6

5

4

3

2

1

0

-

-

-

-

-

-

-

-

Bit

Number

Bit

Mnemonic

Description

7-0

Low Byte of Timer 2.

7

6

5

4

3

2

1

0

-

-

-

-

-

-

-

-

Bit

Number

Bit

Mnemonic

Description

7-0

High Byte of Timer 2 Reload/Capture.

7

6

5

4

3

2

1

0

-

-

-

-

-

-

-

-

Bit

Number

Bit

Mnemonic

Description

7-0

Low Byte of Timer 2 Reload/Capture.
